OEM PART NUMBERS:
• Case IH: 1983221C1 / 1987560C1
• Cummins: 3675159RX
• Delco: 10459460 / 10459463
• Delco: 1117945 / 1117926
SPECIFICATIONS:
• Series: Delco 21SI Type
• Voltage: 12V
• Amperage: 160 Amp
• Design: IR/EF (Internal Regulator / External Fan)
• System: 3-Wire
• Mount Type: J180 Hinge (197.87mm / 7.79 in)
• Shaft: 22.22mm OD (0.875 in) — No Pulley Included
• Mounting: 1/2-13 Threaded + 13.2mm Unthreaded x2
• Polarity: Negative Ground
• Weight: 15.98 lbs / 7.27 kg
• Condition: New
APPLICATIONS:
• Case IH 9210/9230/9240 w/CDC 504 8.3L (1990-1995)
• Case IH 9250/9260 w/Cummins 611ci 10.0L (1990-1995)
• Case IH 9270/9280 w/Cummins 855ci 14.0L (1990-1995)
• Case IH 9310-9390 Steiger/Quadtrac (1995-2000)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
