New Alternator Fits Komatsu 600-821-9220 6008259710 600-825-9730 600-825-9231

11843NA2
KOMATSU PART NUMBERS:
• 600-825-9230, 6008259230
• 600-861-9121, 6008619121
• 600-821-9220, 6008219220
• 600-825-9710, 6008259710
• 600-825-9130, 6008259130
• 600-825-9120, 6008259120
• 600-825-9231, 6008259231
• 600-825-9150, 6008259150
• 600-825-9730, 6008259730
• 600-825-9720, 6008259720
• 600-825-9821, 6008259821
• 600-825-9820, 6008259820
• 600-861-9120, 6008619120
• 600-821-9230, 6008219230
• 600-821-9880, 6008219880
• 600-825-9110, 6008259110
• 600-825-9111, 6008259111
• 600-825-9131, 6008259131
• 600-825-9151, 6008259151
• 600-825-9330, 6008259330
• 600-825-9331, 6008259331
• 600-825-9721, 6008259721
• 600-825-9731, 6008259731
• RKD90A01
• D90A03
• 600-825-9310, 6008259310
• R600-861-9121, R6008619121
• R600-861-9120, R6008619120
• R600-825-9821, R6008259821

NIKKO PART NUMBERS:
• 0-35000-8390, 0350008390
• 0-35000-8040, 0350008040
• 0-35000-8410, 0350008410
• 0-35000-8570, 0350008570
• 0-35000-8573, 0350008573
• 0-35000-8640, 0350008640
• 0-35000-8571, 0350008571
• 0-35000-8572, 0350008572
• 0-35000-8574, 0350008574
• 0-35000-8030, 0350008030
• 0-35000-8350, 0350008350
• 0-35000-8351, 0350008351
• 0-35000-8352, 0350008352
• 0-35000-8360, 0350008360
• 0-35000-8361, 0350008361
• 0-35000-8362, 0350008362
• 0-35000-8380, 0350008380
• 0-35000-8400, 0350008400
• 0-35000-8401, 0350008401
• 0-35000-8402, 0350008402
• 0-35000-8491, 0350008491
• 0-35000-8610, 0350008610
• 0-35000-8611, 0350008611
• 0-35000-8612, 0350008612
• 0-35000-8641, 0350008641
• 0-35000-8690, 0350008690
• 01-35-2021, 01352021
• 01-35-2022, 01352022

CUMMINS PART NUMBERS:
• 4064077

WILSON PART NUMBERS:
• 90-28-4037, 90284037
• 90-28-4037N, 90284037N

SPECIFICATIONS:
• Type: brushless alternator
• Voltage: 24 volt
• Output: 90 amp
• Regulator: internal
• Fan: external
• Ground: negative
• Rotation: clockwise (CW)
• Pulley: 2 groove V-belt, not decoupled
• Mounting: J-180 hinge, 3 holes (one M12 x 1.5 threaded, two 13 mm plain)
• Terminals: B+ M8 x 1.25, R M5
• Plug: 3:30 clock position, rear
• Weight: about 41.84 lb (19.02 kg)
• Condition: New aftermarket

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Was: $1,629.34
Sale: $931.05
Save: 43%
Save: $698.29
Qty:
Free Shipping!

Description

KOMATSU D37 / D39 DOZERS, SAA4D95LE:
• Komatsu D37EX-24 with the SAA4D95LE 3.3L L4 2017-2021
• Komatsu D37EXI-24 with the SAA4D95LE 3.3L L4 2017-2021
• Komatsu D37PX-24 with the SAA4D95LE 3.3L L4 2017-2021
• Komatsu D37PXI-24 with the SAA4D95LE 3.3L L4 2017-2024
• Komatsu D39EX-24 with the SAA4D95LE 3.3L L4 2020-2024
• Komatsu D39EXI-24 with the SAA4D95LE 3.3L L4 2020-2024
• Komatsu D39PX-24 with the SAA4D95LE 3.3L L4 2020-2024
• Komatsu D39PXI-24 with the SAA4D95LE 3.3L L4 2020-2024

KOMATSU D51 DOZERS, SAA4D107E:
• Komatsu D51EX-22 with the SAA4D107E 4.5L L4 2007-2015
• Komatsu D51EX-24 with the SAA4D107E 4.5L L4 2017-2024
• Komatsu D51EXI-24 with the SAA4D107E 4.5L L4 2017-2024
• Komatsu D51PX-22 with the SAA4D107E 4.5L L4 2007-2015
• Komatsu D51PX-24 with the SAA4D107E 4.5L L4 2017-2024
• Komatsu D51PXI-24 with the SAA4D107E 4.5L L4 2017-2024

KOMATSU D61 DOZERS, SAA6D107E:
• Komatsu D61EX-23 with the SAA6D107E 6.7L L6 2012-2016
• Komatsu D61EX-24 with the SAA6D107E 6.7L L6 2015-2021
• Komatsu D61EXI-23 with the SAA6D107E 6.7L L6 2013
• Komatsu D61EXI-24 with the SAA6D107E 6.7L L6 2016-2018
• Komatsu D61PX-23 with the SAA6D107E 6.7L L6 2012-2016
• Komatsu D61PX-24 with the SAA6D107E 6.7L L6 2015-2021
• Komatsu D61PXI-23 with the SAA6D107E 6.7L L6 2013
• Komatsu D61PXI-24 with the SAA6D107E 6.7L L6 2016-2021

KOMATSU D65 DOZERS, SAA6D114E:
• Komatsu D65EX-15 with the SAA6D114E 8.3L L6 2003-2009
• Komatsu D65EX-16 with the SAA6D114E-3E 8.3L L6 2009-2013
• Komatsu D65EX-17 with the SAA6D114E-5B 8.3L L6 2012-2016
• Komatsu D65EX-18 with the SAA6D114E-6A 8.3L L6 2014-2021
• Komatsu D65EXI-18 with the SAA6D114E-6A 8.3L L6 2017-2021
• Komatsu D65PX-15 with the SAA6D114E 8.3L L6 2003-2009
• Komatsu D65PX-16 with the SAA6D114E-3E 8.3L L6 2010-2013
• Komatsu D65PX-17 with the SAA6D114E-5B 8.3L L6 2012-2016
• Komatsu D65PX-18 with the SAA6D114E-6A 8.3L L6 2014-2021
• Komatsu D65PXI-18 with the SAA6D114E-6A 8.3L L6 2015-2016
• Komatsu D65WX-15E0 with the SAA6D114E 8.3L L6 2006-2010
• Komatsu D65WX-16 with the SAA6D114E-3E 8.3L L6 2009-2013
• Komatsu D65WX-17 with the SAA6D114E-5B 8.3L L6 2012-2016
• Komatsu D65WX-18 with the SAA6D114E-6A 8.3L L6 2014-2021
• Komatsu D65EX-15EO with the SAA6D-114E-3 diesel 2007-2010
• Komatsu D65PX-15EO with the SAA6D-114E-3 diesel 2003-2009
• Komatsu D65WX-15EO with the SAA6D-114E-3 diesel 2003-2009

KOMATSU D85 DOZERS, SAA6D125E:
• Komatsu D85EX-15 with the SAA6D125E 11.0L L6 2006-2013
• Komatsu D85EX-18 with the SAA6D125E 11.0L L6 2015-2021
• Komatsu D85EXI-18 with the SAA6D125E 11.0L L6 2016-2021
• Komatsu D85PX-15 with the SAA6D125E 11.0L L6 2003-2013
• Komatsu D85PX-18 with the SAA6D125E 11.0L L6 2014-2021
• Komatsu D85PXI-18 with the SAA6D125E 11.0L L6 2016-2021

KOMATSU D155 DOZERS, SAA6D140E:
• Komatsu D155A-6R with the SAA6D140E 15.2L L6 2009-2016
• Komatsu D155AX-6 with the SAA6D140E 15.2L L6 2006-2016
• Komatsu D155AX-7 with the SAA6D140E 15.2L L6 2012-2016
• Komatsu D155AX-8 with the SAA6D140E 15.2L L6 2014-2021
• Komatsu D155AXI-8 with the SAA6D140E 15.2L L6 2015-2021

KOMATSU D275 DOZERS, SAA6D140E / SDA6D140E:
• Komatsu D275A-5 with the SDA6D140E 15.2L L6 2004-2011
• Komatsu D275A-5R with the SAA6D140E 15.2L L6 2009-2011
• Komatsu D275AX-5 with the SDA6D140E 15.2L L6 2009-2020
• Komatsu D275AX-5E0 with the SAA6D140E 15.2L L6 2006-2011

KOMATSU D375 DOZERS, SAA6D170E / SA6D170E:
• Komatsu D375A-5 with the SAA6D170E 23.2L L6 2002-2009
• Komatsu D375A-5E0 with the SA6D170E 23.2L L6 2002-2010
• Komatsu D375A-6 with the SAA6D170E 23.2L L6 2009-2019
• Komatsu D375A-5EO with the SA6D-170E-3 diesel 2002-2010

KOMATSU D475 DOZERS, SDA12V140E / SAA12V140E V12:
• Komatsu D475A with the SDA12V140E 30.5L V12 1987-2008
• Komatsu D475A-3 with the SDA12V140E 30.5L V12 2001-2006
• Komatsu D475A-5 with the SAA12V140E 30.5L V12 2006-2018
• Komatsu D475A-5 with the SDA12V140E 30.5L V12 2004-2005

KOMATSU WHEEL DOZERS, SAA6D170E:
• Komatsu WD600-6 with the SAA6D170E 23.2L L6 2022-2024
• Komatsu WD600-6R with the SAA6D170E 23.2L L6 2022-2024

SPECIFICATIONS:
• Type: brushless alternator
• Voltage: 24 volt
• Output: 90 amp
• Regulator: internal
• Fan: external
• Ground: negative
• Rotation: clockwise (CW)
• Pulley: 2 groove V-belt, not decoupled
• Mounting: J-180 hinge, 3 holes (one M12 x 1.5 threaded, two 13 mm plain)
• Terminals: B+ M8 x 1.25, R M5
• Plug: 3:30 clock position, rear
• Weight: about 41.84 lb (19.02 kg)
• Condition: New aftermarket
