CATERPILLAR PART NUMBERS: • 3T8192
DELCO PART NUMBERS, IH AND CATERPILLAR: • 1107709
• 1107710 (replaces 1107709)
• 1998280
• 1998282 (replaces 1998280)
• 1109356
• 1109358 (replaces 1109356)
• 1998421 (replaces 1109358)
• 1108278
• 1108373 (replaces 1107710)
DELCO PART NUMBERS, SD300 / 14MT SUPERSESSION: • 1108525
• 1109484 (replaces 1108525)
• 10455600
• 1998460
• 1998599
• 10455601 (replaces 1109484, 1998599)
• 19010617 (replaces 10455601)
PRESTOLITE PART NUMBERS: • 20513003
WILSON PART NUMBERS: • 71-01-4297, 71014297
• 91-01-4255, 91014255
MERCURY MARINE PART NUMBERS: • 50-79604A3, 5079604A3
• 50-79604A1, 5079604A1
VOLVO PENTA PART NUMBERS: • 841377
SPECIFICATIONS: • Type: Delco PG260M family, permanent magnet gear reduction (PMGR)
• Voltage: 12 Volt
• Power: 1.7 kW
• Rotation: Clockwise (CW)
• Pinion: 9 teeth, 25 mm (0.984 in) gear OD
• Mounting: two ears, both 13 mm unthreaded
• Weight: 8.77 lb (3.99 kg)
• Replaces the Delco 10MT / SD300 direct drive starter, about 22.4 lb
