OEM PART NUMBERS:
• 61002316 (All-Makes Number)
• OE: 8600564 / 86000564
• BorgWarner / 61002316
55SI FAMILY CROSS-REFERENCE (24V 275A):
• J180 Hinge Mount: 8600564 / 61002316 (THIS PART)
• 105mm Long Pad Mount: 8600557 / 61006081
55SI FAMILY (24V 250A):
• 105mm Pad: 8600581 / 8600635 / 61006080
• 80mm Pad: 8600453 / 8600483 / 8600737 / 61006082
SPECIFICATIONS:
• Type: Alternator
• Series: 55SI (Family Type 455)
• Voltage: 24V
• Amperage: 275A
• Design: Brushless / Dual Internal Fan (DIF)
• Efficiency: 80% (Best in Class)
• Rotation: Clockwise (CW)
• Mount Type: J180 Hinge Mount
• Fan: External
• Regulator: Internal
• B+ Terminal: 1/2-13 / B- Terminal: 3/8
• S Terminal: 10-24 / I Terminal: 10-24 / R Terminal: 10-24
• Polarity: Negative Ground
• Shaft OD: 0.875 in / 22.22mm
• Remote Sense: Yes (Reduces Battery Charge Time by 50%)
• Indicator Light: Yes / Relay Terminals: Yes
• Frame Length: 8 in (Compact)
• Weight: 44.21 lbs / 20.1 kg
• Condition: New
APPLICATION CATEGORIES:
• Caterpillar Motor Graders (120K-160M), Wheel Loaders (950K-980M), Mining Trucks
• Komatsu Wheel Loaders (WA380-WA800), Motor Graders (GD555-GD675)
• Transit Buses: New Flyer, Gillig, NOVA Bus — Cummins ISL/L9
• Fire / Emergency Vehicles with 24V Systems
• Mining Equipment with 24V Systems
