OEM PART NUMBERS:
• Sure Power/Eaton: 12023A
• Sure Power: 12023A-L
• Sure Power: 12023A-IB
• Sure Power: 12023A-D
• Sure Power: 12023A-DL
• Sure Power: 12023A-B
• Sure Power: I01202-3A
• Cooper Bussmann: RB-BI120A
• Powerline: 22-18
SPECIFICATIONS:
• Amperage: 120 Amps Maximum
• Input Voltage Range: 6V - 50V DC
• Number of Inputs: 1
• Number of Battery Banks: 2
• Ground Type: Negative
• Ignition Terminal: Yes
• Sense Terminal: No
• Operating Temp: -40°C to +93°C
• Insulation to Ground: 500V 60Hz AC Min
• Finish: Blue Anodized (336 hr salt spray rated per ASTM B117)
• Studs: 4
• Mounting Holes: 6 at 0.21"
• Length: 7.48" / 190mm
• Width: 4.528" / 115mm
• Height: 3.307" / 84mm
• Technology: Solid-State Electronics
• Mounting Hardware: Included
COMPATIBLE ALTERNATOR SYSTEMS:
• Delco CS Series alternators (most 1985+ GM vehicles)
• External excitation alternator applications
• External sensing alternator applications
• 120 amp maximum alternator output systems
FITS APPLICATIONS:
• EMS vehicles, fire trucks, ambulances
• Marine, RV, motorhome, camper
• Farm equipment, off-road vehicles
• High-amp stereo / audio systems
• Any dual battery system with 120A max charging
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
