OEM PART NUMBERS:
• Denso: 428000-1420 / 4280001420
• Denso: 428000-1421 / 4280001421
• Denso: 428000-1422 / 4280001422
• Denso: LAY42800-0050 / LAY42800-0051
• Prestolite: MS2-506 / MS2506
• Bosch Long Haul: SR9922LH
• Case IH: 3601668C91
SPECIFICATIONS:
• Type: PLGR (Planetary Gear Reduction)
• Voltage: 12V
• Power: 5kW / 6.7HP
• Rotation: CW (Clockwise)
• Teeth: 12
• Gear OD: 1.799in / 45.7mm
• Solenoid Position: 82 Degrees
• Mounting: Triple 16.8mm Unthreaded Ears
• Housing: Rotatable
• Ground: Isolated
• Replaces: 12-Tooth 40MT and 42MT Delco Starters
• Weight: 39.62 lbs / 18.01 kg
• Condition: New
CATERPILLAR ENGINE APPLICATIONS:
• Cat 3208 V8 Diesel 10.4L 636ci 210-375HP — Ford Trucks (1983-1999)
• Cat 3305 6-Cyl Diesel 10.5L — Western Star (1974-1978)
• Cat 3306 6-Cyl Diesel 10.5L 638ci — Western Star (1974-1984)
