OEM PART NUMBERS:
• Cummins: 3675254RX / 3675254RX
• Delco: 19009951 / 19009951
• Delco: 19009959 / 19009959
SPECIFICATIONS:
• Family: Delco 19SI
• Voltage: 12V | Amperage: 105A
• Fan: External | Regulator: Internal
• Rotation: Clockwise (CW)
• B+ Terminal: M6-1.0
• R Terminal: M4-1.0
• B- Terminal: M10-1.5
• 3-Wire System
• Mounting Foot: 2" / 50.8mm
• Polarity: Negative
• Weight: 15.4 lbs / 7.0 kg
• Condition: New
APPLICATIONS (HYSTER LIFT TRUCKS):
• Hyster H120XM — Cummins 6B 5.9L / 6C 8.3L Diesel (1999-2007)
• Hyster H230HD — Cummins 6B 5.9L / 6C 8.3L Diesel (2002-2007)
• Hyster H280HD — Cummins 6B 5.9L / 6C 8.3L Diesel (2002-2007)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
