OEM PART NUMBERS:
• Delco: 1113409 / 1113642 / 1113647 / 1113685 / 10461665
• Delco: 1113398 / 1113432 / 1113446
• Delco: 323-731 / 323731
• IHC/Navistar: 381035R92 / 381035R91
• IHC: 102263A1 / 104193A1 / 104208A1 / 104210A1 / 104253A1 / 539089R92
• Case: 104208A1 / 104208A1R
SPECIFICATIONS:
• Unit Type: Delco 35MT
• Starter Type: DD (Direct Drive)
• Voltage: 12V
• Power: 3.5 kW
• Rotation: CCW (Counter-Clockwise)
• Tooth Count: 10
• Gear OD: 1.571" / 39.9mm
• Solenoid Position: 315 Degrees
• Mounting: 3 x 0.410" Unthreaded Ears
• Weight: 53.5 lbs / 24.32 kg
• Condition: New
INTERNATIONAL / CASE-IH APPLICATIONS:
• International Tractors 766D-4166D w/D-360/361/407/414/DT-436/DV-550 Diesel (1963-1976)
• International Industrial 2806/2826/2856/21256/21456 Diesel
• Case/International Combines 815/915 Diesel (1969-1976)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
