New 12V Starter Fits Chevrolet Impala 1975-76 4.4L 4.6L 5.0L 5.3L S114-254S1bx

18492D1
WILSON PART NUMBERS:
• 91-25-1122, 91251122
• 91-25-1122N, 91251122N

HITACHI PART NUMBERS:
• PP106, PP-106

GM (CHEVROLET PERFORMANCE) MINI STARTER NUMBERS:
• 12361146
• 12363128

INTERCHANGE NUMBERS:
• S114-254S1BX, S114254S1BX
• S114-823SBX, S114823SBX
• SD114-254S1, SD114254S1

SPECIFICATIONS:
• Type: mini offset gear reduction (OSGR) starter
• Voltage: 12 Volt
• Power: 1.4 kW
• Rotation: Clockwise (CW)
• Teeth: 9
• Gear OD: 25.1 mm / 0.988 in
• Flywheel: 153 or 168 tooth ring gear
• Mounting: 3 unthreaded 10 mm holes, rotatable block, 3 clocking positions
• Length: about 210 mm / 8.28 in
• Weight: about 11.8 lb / 5.35 kg
• Used on: Chevrolet Corvette 1955-1986 and Chevrolet cars, trucks and Sedan Delivery 1955-1961
• Condition: New aftermarket, not a Hitachi, GM or Delco Remy branded unit

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Was: $324.78
Sale: $185.59
Save: 43%
Save: $139.19
Qty:
Free Shipping!

Description

⚠️ NEW AFTERMARKET MINI GEAR REDUCTION (OSGR) STARTER, 12V 1.4 KW, 9 TOOTH, CW:
• Offset gear reduction (OSGR), 12 volt, 1.4 kW, clockwise (CW)
• 9 tooth pinion, gear OD 25.1 mm (0.988 in), for 153 and 168 tooth flywheels
• Three 10 mm unthreaded mounting holes, rotatable mounting block with 3 clocking positions
• About 210 mm (8.28 in) long, about 11.8 lb (5.35 kg)
• Listed for Chevrolet built V8 engines; Pontiac, Buick and Oldsmobile built engines, inline 6 and diesel engines are not listed

CHEVROLET CORVETTE:
• Chevrolet Corvette with the 4.3L 265 V8 1955
• Chevrolet Corvette V8 1956-1986
• Chevrolet Corvette with the 4.6L 283 V8 1957-1961
• Chevrolet Corvette with the 5.4L 327 V8 1962-1968
• Chevrolet Corvette with the 6.5L 396 V8 1965
• Chevrolet Corvette with the 7.0L 427 V8 1966-1969
• Chevrolet Corvette with the 5.7L 350 V8 1969-1981
• Chevrolet Corvette with the 7.4L 454 V8 1970-1974
• Chevrolet Corvette with the 5.0L 305 V8 1980

CHEVROLET NOMAD, ONE-FIFTY, TWO-TEN, DEL RAY AND YEOMAN:
• Chevrolet Del Ray with the 4.3L 265 V8 1957
• Chevrolet Del Ray with the 4.6L 283 V8 1957-1958
• Chevrolet Nomad with the 4.3L 265 V8 1955-1957
• Chevrolet Nomad with the 4.6L 283 V8 1957-1961
• Chevrolet One-Fifty with the 4.3L 265 V8 1955-1957
• Chevrolet One-Fifty with the 4.6L 283 V8 1957
• Chevrolet Two-Ten with the 4.3L 265 V8 1955-1957
• Chevrolet Two-Ten with the 4.6L 283 V8 1957
• Chevrolet Yeoman with the 4.6L 283 V8 1958

CHEVROLET TRUCK AND SEDAN DELIVERY:
• Chevrolet 3A with the 4.6L 283 V8 1959
• Chevrolet 3B with the 4.6L 283 V8 1959
• Chevrolet 3C with the 4.6L 283 V8 1959
• Chevrolet 3D with the 4.6L 283 V8 1959
• Chevrolet 3E with the 4.6L 283 V8 1959
• Chevrolet 3F with the 4.6L 283 V8 1959
• Chevrolet 3G with the 4.6L 283 V8 1959
• Chevrolet Sedan Delivery with the 4.3L 265 V8 1955-1957
• Chevrolet Sedan Delivery with the 4.6L 283 V8 1957-1958
• Chevrolet Truck with the 4.3L 265 V8 1955-1957
• Chevrolet Truck with the 4.6L 283 V8 1957-1960
