OEM PART NUMBERS:
• 104210-1240 / 1042101240
• Reman: 9764219-124 / 9764219124
• Honda: 31100-RV0-A01 / 31100RV0A01
• Honda: 31100-RV0-305
• Honda: CSJ24
• Honda Reman: 31100-RV0-A01RM / 31100RV0A01RM
• Honda Reman Service: 06311-RV0-505RM / 06311RV0505RM
SPECIFICATIONS:
• Type: Alternator | Series: Hairpin
• Voltage: 12V | Amperage: 130A | Rotation: CW | Polarity: Negative
• Fan: Internal (IF) | Regulator: Internal (IR)
• Pulley Class: SD6 | Grooves: 6-Groove Decoupler | Pulley OD: 65.3mm
• Case OD: 138.3mm | Plug Code: 298 | Plug Orientation: Rear
• Terminals: IG-C-L-FR | Weight: 15 lbs | Condition: New
APPLICATIONS:
• Honda Odyssey V6 3.5L 3471cc J35Z6 SOHC 24V i-VTEC 248HP (2011-2013)
• Honda Pilot V6 3.5L 3471cc J35Z5 SOHC 24V i-VTEC 250HP (2012-2015)
• Honda Ridgeline V6 3.5L 3471cc J35Z5 SOHC 24V i-VTEC 250HP (2012-2014)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
