OEM PART NUMBERS:
• Cummins: 4996709 / 499670900
• Denso: 428000-7120 / 4280007120
• Denso: 428000-7121 / 4280007121
• Denso: 428000-7122 / 4280007122
• Denso: 438000-3730 / 4380003730
SPECIFICATIONS:
• Type: PLGR (Planetary Gear Reduction)
• Denso Series: PA90L
• Voltage: 24V
• Power: 7.8kW / 10.45HP
• Rotation: CW (Clockwise)
• Teeth: 10
• Gear OD: 40mm / 1.575in
• Overall Length: 245mm / 9.646in
• Registry OD: 88.7mm / 3.492in
• Mounting: 2 Ears, 11.2mm Unthreaded
• Ear Center to Center: 126.6mm / 4.984in
• Wet Clutch Seal: Yes
• Studs: M12 B+ and Ground, M10 Motor, M5 Threaded S Tab
• Weight: 18.56 lbs / 8.44 kg
• Condition: New
APPLICATION:
• Cummins 6CTA 8.3L Diesel
• Cummins B/ISB/QSB Series Diesel 2.8L-8.3L
• Ingersoll Rand XP285-W
• Doosan w/ Cummins 6CTA
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
