OEM PART NUMBERS:
• Hella: 8EL-737-787-001 / 8EL737787001
• Lucas Industries: LEA0403 / NAB900M
• Orme Electromeccanica: VA04014
• Prestolite: 66021126M / 66021590M
• Sole Diesel: 13817100 / 13.201.900
SPECIFICATIONS:
• Type: Marine Alternator
• Unit Type: Prestolite / Lucas A127 Style
• Voltage: 12V
• Amperage: 70A
• Rotation: CW (Clockwise)
• Fan: External (EF)
• Regulator: Internal (IR)
• Pulley Type: 1-Groove V-Belt Solid
• Pulley OD: 2.673 in / 67.9mm
• Mounting: 3-Hole Multimount Adjusting Ear
• Mounting Ear 1: 8mm Unthreaded
• Mounting Ear 2: 8.1mm Unthreaded
• Mounting Ear 3: 8.2mm Unthreaded
• Mounting Ear 1 Thickness: 0.421 in / 10.7mm
• Mounting Ear 2 Thickness: 0.417 in / 10.6mm
• Mounting Ear 3 Thickness: 0.803 in / 20.4mm
• Regulator Clock Position: 9:00
• B+ Terminal: M6x1.00 (Large Spade)
• W Terminal: M5x0.8 Spade Combo
• D+ Terminal: Small Spade
• Polarity: Insulated Return
• Weight: 14 lbs
• Condition: New
ISUZU 4-CYL MARINE APPLICATIONS:
• Isuzu 4L55 2179cc 4-Cyl Marine Diesel (1985-1996)
• Isuzu 4LB1 1499cc 4-Cyl Marine Diesel (1985-1996)
• Isuzu 4LC1 1735cc 4-Cyl Marine Diesel (1985-1996)
• Isuzu 4LE1 2179cc 4-Cyl Marine Diesel (1985-1996)
• Isuzu 4L35 1499cc / 4L42 1732cc 4-Cyl Marine Diesel (1985-1996)
• Isuzu 4J.65 / 4JG1 3059cc 4-Cyl Marine Diesel (1985-1996)
• Isuzu 3LB1 1124cc 3-Cyl Marine Diesel (1985-1996)
• Motorola Marine Engines, Various Models (1985)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
