12V 36 Amp Alternator Compatible With Mahindra 475 485 575 2810 3325 3505 3510 E350 Tractor Lucas

OEM PART NUMBERS:
• Lucas TVS: 26021268

SPECIFICATIONS:
• Family: Lucas A115
• Voltage: 12V
• Amperage: 36A
• Rotation: CW (Clockwise)
• Fan: External
• Regulator: Internal
• Polarity: Negative
• Pulley: Solid, 1 Groove, 72.8mm / 2.866" OD
• Mount Hole 1: M8x1.25 Threaded
• Mount Hole 2: Unthreaded
• B+ Terminal: M6x1.00
• D+ Terminal: Spade
• Weight: 11 lbs
• Condition: New

APPLICATION:
• Mahindra E350, 475/475 DI, 485/485 DI, 575/575 DI
• Mahindra 2810, 3325, 3505, 3510, 3525
• Mahindra 4005, 4025, 4035, 4110, C4005
• Mahindra 4500, 4505, 4525
• Mahindra 5005, 5500, 5530
• Mahindra 6500, 6530

12V 36A Alternator — Mahindra Agricultural Tractors Lucas A115
New 12V 36 amp alternator for Mahindra agricultural tractors using the Lucas A115 platform. Fits the E350, 475, 475 DI, 485, 485 DI, 575, 575 DI, 2810, 3325, 3505, 3510, 3525, 4005, 4025, 4035, 4110, 4500, 4505, 4525, 5005, 5500, 5530, 6500, 6530, and C4005. Features external fan cooling with internal voltage regulator, clockwise rotation, and negative polarity. Solid single-groove pulley with 72.8mm (2.866") outer diameter. Spool mount design with M8x1.25 threaded primary ear and unthreaded secondary ear. M6x1.00 B+ terminal and spade-type D+ terminal. Weighs 11 lbs. Direct replacement for Lucas TVS 26021268.
