New 24V Starter Compatible With Iveco 110 120 150 160 Liebherr R981 A903 Lrs01936 1183122

SIA0008B4
DEUTZ / EQUIPMENT PART NUMBERS:
• Deutz (KHD) 0117 9586, 01179586
• Deutz (KHD) 0118 3122, 01183122, 1183122
• Ahlmann 2300088A
• Fuchs 541 165 6432, 5411656432
• Liebherr 702 60 25 A, 7026025A, 620 06 62
• Iveco 42522653

BOSCH / LUCAS / HELLA / MARELLI:
• Bosch 0 001 263 052, 0001263052
• Bosch 0 001 364 100, 0 001 364 301
• Lucas LRS01936
• Hella CS501, CS 501
• Magneti Marelli MSR705

LETRIKA (ISKRA) / MAHLE:
• IS1255, 11.131.770, AZF4198
• 11.130.842
• Mahle MS66

SPECIFICATIONS:
• Type: Letrika / Bosch planetary gear reduction (PLGR)
• Voltage: 24 Volt
• Power: 4.0 kW
• Rotation: Clockwise (CW)
• Pinion: 9 teeth, module 3, 34.8 mm (1.37 in) OD
• Span over two teeth: 14.36 mm
• Mounting: 3 unthreaded 10.9 mm holes
• Design: dust-proof
• Weight: about 20 lbs (9.2 kg)

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Was: $423.78
Sale: $242.16
Save: 43%
Save: $181.62
Qty:
Free Shipping!

Description

⚠️ 24 VOLT 4 KW 9 TOOTH GEAR REDUCTION STARTER:
• 24V, 4.0 kW, clockwise, planetary gear reduction, 9 tooth module 3, 34.8 mm OD
• 3 unthreaded 10.9 mm mounting holes, dust-proof, about 20 lbs
• Replaces Deutz 0117 9586 / 0118 3122, Fuchs 541 165 6432, Bosch 0001263052

MAGIRUS-DEUTZ AND IVECO TRUCKS, KHD 913 6.1L:
• 1975-1982 Magirus-Deutz M130 D9/11FL, D12/15K, AK, D14/16FL, F6L913
• 1975-1982 Magirus-Deutz M160 D11/16FL, D11FS, D12/15K, AK, BF6L913
• 1983-1989 Iveco 120-16ANW; 1983-1991 150-16AN; 1983-1984 160-16AR
• 1986-1991 Iveco 110-17AW; 1989-1996 120-17ANW; 1989-up 160-17AN

DEUTZ-FAHR COMBINES:
• 1973-1974 Deutz-Fahr M130, F6L913 6.1L
• 1973-1974 Deutz-Fahr M160, BF6L913 6.1L

LIEBHERR, FUCHS, IRMER ELZE, MECALAC:
• 1974-1990 Liebherr R981 crawler excavator, BF6L913
• 1992-1996 Liebherr A903 wheeled excavator, F6L912
• 1975-1986 Fuchs 118M, KHD F6L912; Fuchs MHL331, BF6M2012C
• 1977-1986 Irmer u. Elze S1051 SLS; 1986-up S1131 7SL, KHD F6L912
• 2010-up Mecalac AS150e, TCD 2012 L04; AS210e, TCD 2012 L06
