OEM PART NUMBERS:
• Aprilia: 580442 / AP8580124 / AP8580124
• Aprilia/Piaggio: 82611R / 82611R5
• Piaggio: 829414
• Mitsuba: SM14-225 / SM14225
SPECIFICATIONS:
• Type: PMDD (Permanent Magnet Direct Drive)
• Voltage: 12V / Rotation: CCW (Counter-Clockwise)
• Teeth: 9 / Gear OD: 11.3mm (0.445in)
• Length: 140mm (5.512in) / Registry OD: 29.8mm (1.173in)
• Mounting: (2) 7mm Unthreaded Ears
• Weight: 0.92kg (2.03 lbs)
• Engine Platform: Piaggio Leader 125-200cc 4-Stroke
• Condition: New
SCOOTER APPLICATIONS:
• Aprilia: Atlantic/Mojito/Scarabeo/SportCity/SR 125-200cc (2003-2013)
• Benelli: Adiva 125/150 (2001-2006)
• Piaggio: Fly 125/150, BV 200, Liberty 125, Typhoon 125, Carnaby 125 (2003-2020)
• Vespa: ET4 150, LX 150, LXV 150, S 150, GT 200 (2001-2016)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
