OEM PART NUMBERS:
• 0-122-469-001, 0-122-469-003
• Caterpillar: 6N9294, 7N9720, 7T6172, 0R3482, 0R3668, 0R5217, 100-5046, 3V8825, 9G9538, 2P1204, 3T6352, 9S4070
• John Deere: SE501370, AT85458, TY6681, TY25949
• 2303JB / Volvo: 10039152
SPECIFICATIONS:
• Product Type: Alternator — Type
• Voltage: 24V DC
• Amperage: 35A
• Rotation: CW (Clockwise)
• Fan: External (Included)
• Regulator: Internal — 12:00 Clock Position
• Activation: Ignition / Trio
• Mount: J180
• B+ Terminal: 7/16-14 Threaded
• D+ Terminal: M4x0.7
• B- Terminal: M5x0.8
• Polarity: Negative Ground
• Shaft OD (Pulley End): 0.875" / 22.22mm
• Mtg Ear 1: 7/16-14 Threaded, 0.563" Thick
• Mtg Ear 2: 13mm Unthreaded, 0.551" Thick
• Mtg Ear 3: 13mm Unthreaded, 0.787" Thick
• Weight: 24.195 lbs / 11 kg
• Condition: New — Includes Fan
NUMBER: 12165
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
