OEM PART NUMBERS:
• Trombetta: 114-2411-020
• Trombetta: 114-2411-020-02
• White Rodgers: 586-114111
• White Rodgers: 586-114111-3
• White Rodgers: 586-905
• White Rodgers: 586-905S1
• White Rodgers: 586114
• White Rodgers: 586-114112-6A
• Prestolite: 15-551
• Prestolite: SBJ4401
• Johnson Electric: 5122240
• Johnson Electric: SO51222
• Cummins: 3050692
• Cummins: 3050692C
• Skyjack: 103101
• Skyjack: 146475
• JLG: 3740068
• EZGO: 20468G3
• Grove: 7750000111
• Misc: 586-114111-5
• Misc: 6C025
SPECIFICATIONS:
• Voltage: 24V DC
• Continuous Amps: 225A
• Surge Amps: 600A
• Terminals: 4 (SPNO)
• Duty Cycle: Continuous
• Contact Material: Silver Alloy
• Case Material: Plastic
• Mounting: Flat 180 (F180)
• Operating Temp: -40°C to +85°C
• Terminal Hardware: (2) 5/16-24 & (2) 10-32
• Weight: 1.8 lbs / 0.82 kg
FITS SKYJACK SCISSOR LIFTS:
• SJIII3015, SJIII3215, SJIII3219, SJIII3220, SJIII3226, SJIII4620
FITS JLG SCISSOR LIFTS:
• CM1432, CM1732, CM2033, CM2046, CM2546, CM2558
FITS CUMMINS / KOBELCO:
• Cummins N Series Engines / Generators
• Kobelco SK130, SK150, SK200, SK220, SK250, SK300 Excavators
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
