OEM PART NUMBERS:
• Waltco: 70391100 / 70392800 / 70392900
• Fenner Stone: 1175-AC / 1185-AC / 1785-AC / 1787-AC / 1788-AC / 1789-AC / 1931-AC / 1997-AC / 2578-AC
• Prestolite: 46-4048 / 46-4229 / MUE-6114 / MUE-6114S / MUE-6212
• Maxon: 222423 / 226578 / 226579
• Anthony: A150265
• Delamerica: 25163 / 25169
• Leyman: P46340
• Venco: 13850
• Tommy Lift: 42 FENNER
• Bosch: 9130450083
• Johnson Electric: MM18896
• Barsanco: 520-001
• Western Motor: W-9787 / W-9789 / W-8989
• Ref: D-6000 / DCM-0013 / T-8789 / 02-1020 / FN2-0001N / M-340
SPECIFICATIONS:
• Voltage: 12V
• Rotation: CW (Clockwise)
• Power: 1.7kW / 2.28 HP
• Shaft OD: 12.2mm (0.480 in) - 9 Straight Splines
• Terminal: 5/16-24 (1 Post)
• Field Housing OD: 113.8mm / 4.480 in
• Overall Length: 195mm / 7.677 in
• Bearings: Double Ball Bearing
• Type: Standard Duty
• Weight: 16.2 lbs / 7.36 kg
• Condition: New
APPLICATION:
• Waltco / Dell / Maxon / Tommy Gate / Anthony / Leyman / Big Joe / Venco Liftgates
• Curtis / Sno-Way / Boss / Hiniker / Northman / Prime Mover Snow Plows
• Air-Flo / Buyers Snow Removal Equipment
• Fenner Stone Hydrylac / Fenner Fluid Power Pump Systems
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
