CANIMEX:
• 120Z402H
• 120Z402H1
• 120Z402H2
• W4BB1601
LEESON:
• 108046
• 108047
• C4D17NK10B
• C4D17NK68
• C4D17NK6B
• C4D17NK73
• C4D17NK7E
SCOTT MOTORS:
• 4BB-01601
• 4BB-1601
SPECIFICATIONS:
• Voltage: 12V DC
• Power: 12 HP
• Speed: 1800 RPM
• Rotation: Bi-Rotational (reversible)
• Field Housing OD: 4.5 inches
• Field Housing Length: 192mm
• Overall Length: 12.00 inches
• Mounting Bracket Distance: 210mm
• Shaft Diameter: 5/8 inch
• Shaft Length: 50mm
• Shaft Style: Keyed (keyway)
• Terminal 1: 5/16-24 threaded
• Terminal 2: 5/16-24 threaded
• Housing: Cast aluminum with black powder coat
• End Covers: Cast aluminum
• Weight: 17.6 lbs (7.98 kg)
FEATURES:
• Bi-rotational design for forward/reverse operation
• Cast aluminum construction for durability
• Black powder coat finish for corrosion resistance
• Reliable replacement for Scott, Leeson, Dayton, Canimex motors
