OEM PART NUMBERS:
• Kubota: 15425-63010 / 1542563010, 15425-63011 / 1542563011, 15425-63012 / 1542563012, 15425-63013 / 1542563013
• Kubota: 15425-63014 / 1542563014, 15425-63015 / 1542563015, 15425-63016 / 1542563016
• Kubota: 16652-63012 / 1665263012, 16652-63013 / 1665263013
• Kubota: 17490-63014 / 1749063014, 1K371-63010 / 1K37163010, 1C010-63014 / 1C01063014
• Kubota: KEARS-17490 / KEARS17490, 17331-63014 / 1733163014, 17331-63016 / 1733163016
• Kubota: 17123-63014 / 1712363014, 77700-06124 (Reman)
• Denso: 228000-4570 / 2280004570, 228000-4571 / 2280004571, 228000-4572 / 2280004572, 228000-4573 / 2280004573
• Denso: 228000-4750 / 2280004750, 228000-4752 / 2280004752
• Denso: 228000-5270 / 2280005270, 228000-5271 / 2280005271, 228000-5272 / 2280005272, 228000-5273 / 2280005273
• Denso: 228000-527 / 228000527, 028000-9030 / 0280009030, 028000-9031 / 0280009031, 028000-9032 / 0280009032
• Denso: 228000-0690 / 2280000690, 228000-0691 / 2280000691, 428000-2030 / 4280002030
• Denso Reman: 9722809-457 / 9722809457, 9722809-475 / 9722809475
• Case: 126895A1 / Gehl: 127592 / Prestolite: 20513033
• Yamaha: 1MC81890-01 / 1MC8189001
SPECIFICATIONS:
• Type: OSGR (Offset Gear Reduction)
• Voltage: 12V
• Power: 2.0 kW / 2.68 HP
• Rotation: Clockwise (CW)
• Teeth: 9
• Gear OD: 33.5mm / 1.319in
• Length: 184.6mm / 7.268in
• Mounting: Two 11.2mm ID Unthreaded Holes, 104.4mm Center-to-Center
• Registry OD: 82.3mm / 3.24in
• Terminal: M8-1.25 B+ & Motor Studs, Male Spade S Terminal
• Weight: 10.91 lbs / 4.96 kg
• Condition: New
EQUIPMENT APPLICATIONS:
• Case Trencher 560 (1994-2003), 6010 (1997-2007), Uni-Loader 1838 (1995-1999)
• Gehl SL4625 / SL4625DX / SL4625SX Skid Steers (1992-2002)
• Thomas T153/T153S (2000-2002), T173 (1996-2006), T183/T203 (1989-1994)
• Kubota KX121-2/2S, KX161-2/2S Excavators / R510, R520BU-1A Loaders
• Morooka MST300VD/VDL/VDR Rubber Track Carriers
• Kubota Engines: V2203, D1703, D1803, V2403, WG2503
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
