REPLACES:
WHITE RODGERS: 124-305111, 124-910-111
PRESTOLITE: 15-323
JOHNSON ELECTRIC: 5121440, 512440, SO51214,124-305111-5, 6C023
PRESTOLITE: 15-323, SBD4201A
WHITE RODGERS: 124-305111, 124-305111-3, 124-910-111, 124-910S1
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
NEW WHITE RODGERS 200 AMP 6 TERMINAL 12VOLT CONTINUOUS DUTY SOLENOID 124-305111
OEM(S): WHITE RODGERS
VOLTAGE: 12
CONTINUOUS AMPS: 200 NO/50 NC
SURGE AMPS: 600 NO/200 NC
CONDITION: NEW
MOUNTING: FLAT 180 (F180)
DUTY CYCLE: CONTINUOUS
CASE MATERIAL: METAL
CONTACT MATERIAL: SILVER
NUMBER OF TERMINALS: 6
NOTES:
SPDT
ISOLATED COIL
INCLUDES TERMINAL HARDWARE
(4) 5/16-24 TERMINALS & (2) 10-32 TERMINAL
DIAGRAM(S):
CAUTION: ALWAYS USE A BACK-UP WRENCH TO HOLD THE BOTTOM NUT WHEN TIGHTENING
