Alternator Compatible With Tcm Equipment Lr135-86C Lr135-86F Lr135-95 Lr135-95B 5812003410

12115*4
HITACHI PART NUMBERS:
• LR135-86, LR13586
• LR135-86C, LR13586C
• LR135-86F, LR13586F
• LR135-95, LR13595
• LR135-95B, LR13595B
• LR135-95BN, LR13595BN
• LR135-95BR, LR13595BR
• LR135-115, LR135115
• LR135-116, LR135116
• LR135-125, LR135125
• LR135-127, LR135127
• LR135-127N, LR135127N
• GD204293-E, GD204293E
• GD205008-E, GD205008E

ISUZU PART NUMBERS:
• 5-81200-341-0, 5812003410
• 5-81200-341-1, 5812003411
• 5-81200-338-1, 5812003381
• 8-94423-756-0, 8944237560
• 5-81200-328-1, 5812003281
• 5-81200-338-0, 5812003380
• 8-94153-882-1, 8941538821
• 5-00181-010-0, 5001810100

ISEKI PART NUMBERS:
• 6581-200-338-0, 65812003380
• 6581-200-338-0A, 65812003380A
• 6581-200-349-0, 65812003490

EQUIPMENT MAKER PART NUMBERS:
• Takeuchi I8-94423-756-0, I8944237560
• ASV 0301-719, 0301719

OTHER REPLACEMENT NUMBERS:
• Valeo 436530
• Valeo 436507
• Wilson 90-25-1110, 90251110
• Wilson 90-25-1102, 90251102
• Lucas LRA01826, LRA1826
• Lucas LRA00685, LRA685
• Lucas LRA02589, LRA2589
• Prestolite 20130177
• Bosch 0-986-034-311, 0986034311
• Denso 210-9000, 2109000
• Denso 211-9000, 2119000
• Hella 8EL 726 271-001, 8EL726271001

SPECIFICATIONS:
• Type: alternator, internal regulator, external fan
• Voltage: 12 volt
• Output: 35 amp
• Rotation: clockwise (CW)
• Regulator plug position: 1:30
• Pulley: single groove V-belt pulley, about 70 mm
• B+ terminal: M5 x 0.8 stud
• Polarity: negative ground
• Weight: 9.88 lb (4.49 kg)
• Condition: New aftermarket

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Was: $318.31
Sale: $181.89
Save: 43%
Save: $136.42
Qty:
Free Shipping!

Description

ISEKI TRACTORS AND ENGINES (1982-1988):
• Iseki TE3210 tractor with the 1.2L 3 cylinder diesel, 1982-1988
• Iseki TL1700 tractor, 1982-1988
• Iseki TL1900 tractor with the 3 cylinder diesel, 1982-1988
• Iseki TL2100 tractor with the 3 cylinder diesel, 1982-1988
• Iseki TL2300 tractor with the 3 cylinder diesel, 1982-1988
• Iseki TL2500 tractor with the 3 cylinder diesel, 1982-1988
• Iseki TL2700 tractor with the 3 cylinder diesel, 1982-1988
• Iseki TU1900 tractor with the 1.2L 3 cylinder diesel, 1982-1988
• Iseki TU2100 tractor with the 1.2L 3 cylinder diesel, 1982-1988
• Iseki 3AF1-BL industrial engine, 1982-1988

TCM FORKLIFTS WITH THE 4FE1 (1984-2005):
• TCM FD9Z forklift with the 4FE1 engine, 1984-2005
• TCM FD10Z forklift with the 4FE1 engine, 1984-2005
• TCM FD14Z forklift with the 4FE1 engine, 1984-2005
• TCM FD15Z forklift with the 4FE1 engine, 1984-2005
• TCM FD18Z forklift with the 4FE1 engine, 1984-2005
• TCM FD20Z forklift with the 4FE1 engine, 1984-2005
• TCM FD23Z forklift with the 4FE1 engine, 1984-2005
• TCM FD25Z forklift with the 4FE1 engine, 1984-2005

KOMATSU FORKLIFTS (2001-2012):
• Komatsu FD10-15 forklift with the Isuzu C240-1-F L4 2.4L (145 cid) diesel, 2003-2012
• Komatsu FD10-16 forklift with the Isuzu C240-1-F L4 2.4L (145 cid) diesel, 2003-2012
• Komatsu FD18-16 forklift with the Isuzu C240-1-F L4 2.4L (145 cid) diesel, 2001-2012
• Komatsu FD20J-12 forklift with the Isuzu C240-1-F L4 2.4L (145 cid) diesel, 2001-2012
• Komatsu FD20J-14 forklift with the Isuzu C240-1-F L4 2.4L (145 cid) diesel, 2001-2012
• Komatsu FD25J-12 forklift with the Isuzu C240-1-F L4 2.4L (145 cid) diesel, 2001-2012
• Komatsu FD25J-14 forklift with the Isuzu C240-1-F L4 2.4L (145 cid) diesel, 2001-2012
• Komatsu FD30J-12 forklift with the Isuzu C240-1-F L4 2.4L (145 cid) diesel, 2001-2012
• Komatsu FD30J-14 forklift with the Isuzu C240-1-F L4 2.4L (145 cid) diesel, 2001-2012
• Komatsu FD20H-12 forklift with the Isuzu 4JG2 L4 3.0L (187 cid) diesel, 2003-2012
• Komatsu FD25H-12 forklift with the Isuzu 4JG2 L4 3.0L (187 cid) diesel, 2003-2012
• Komatsu FD30H-12 forklift with the Isuzu 4JG2 L4 3.0L (187 cid) diesel, 2003-2012

GEHL, TAKEUCHI AND ASV LOADERS:
• Gehl SL3410 skid steer with the Isuzu 3KC1 / 3KCR1, 1985-1997
• Takeuchi TL126 loader, 1986-1992
• Takeuchi TL26 track loader with the Isuzu 4JB1 2.8L, 1992-1999
• ASV 2800 Posi-Track loader with the Isuzu 4JB1 2.8L, 1994-2004
• ASV 2810 Posi-Track loader with the Isuzu 4JB1 2.8L, 1998-2004
• ASV MD-70 Posi-Track loader with the Isuzu 4JB1 2.8L, 1990-2001

ISUZU INDUSTRIAL ENGINES AND GENSETS:
• Isuzu industrial equipment with the 4JB1 engine, 1986-2007
• Isuzu industrial equipment with the 3AE1 engine, 1995-2007
• Isuzu industrial equipment with the C240 engine, 1995-2007
• Isuzu 4BD1 and 4BG1 industrial diesel (Isuzu 8-94423-756-0)
• MQ Power DCA-25SSI 20 kW genset with the Isuzu C240 (QD60), 2001-2011

SPECIFICATIONS:
• Type: alternator, internal regulator, external fan
• Voltage: 12 volt
• Output: 35 amp
• Rotation: clockwise (CW)
• Regulator plug position: 1:30
• Pulley: single groove V-belt pulley, about 70 mm
• B+ terminal: M5 x 0.8 stud
• Polarity: negative ground
• Weight: 9.88 lb (4.49 kg)
• Condition: New aftermarket
