OEM PART NUMBERS:
• Kohler: 12-098-21-S / 12-098-21 (Current Part Number)
• Kohler: 12-098-19-S (Superseded by 12-098-21-S)
• Kohler: 12-098-14-S / 12-098-14 (Superseded by 12-098-21-S)
• Kohler: 12-098-12-S / 12-098-12
• Kohler: 12-098-09-S / 12-098-09
• Kohler: 12-098-06-S / 12-098-06
• Kohler: 12-098-05-S / 12-098-05
• United Technologies: 5239740-M030SM / SM52397
• United Technologies: 5278440-M030SM / SM52784
• United Technologies: 5667040-M030SM / SM56670
SPECIFICATIONS:
• Voltage: 12V DC
• Starter Type: PMDD (Permanent Magnet Direct Drive)
• Rotation: CCW (Counterclockwise)
• Tooth Count: 13
• Gear OD: 38.3mm / 1.508"
• Overall Length: 198mm / 7.8"
• OD Housing: 78.4mm / 3-1/16"
• Mounting Ears: (2) 8.0mm ID Unthreaded
• Mounting Hole Distance: 66mm / 2.6"
• Field Housing Length: 88mm
• Terminal: 1 (Battery Terminal on CE Plate)
• Weight: 5.1 lbs / 2.32 kg
• Condition: New
SUPERSESSION CHAIN:
• 12-098-05 → 12-098-12-S → 12-098-14-S → 12-098-19-S → 12-098-21-S (Current)
ENGINE APPLICATION:
• Kohler Command CH11-CH15, CH410-CH450 (Horizontal) 9-15 HP
• Kohler Command CV12.5, CV14, CV15, CV460 (Vertical) 12.5-15 HP
PRODUCT NOTICE:
