OEM PART NUMBERS:
• BMW: 12-41-7-521-116 / 12417521116 / 12-41-7-521-122 / 12417521122 / 12-41-7-521-123 / 12417521123
• BMW: 12-41-7-526-236 / 12417526236 / 12-41-7-594-292 / 12417594292 / 12-41-7-610-343 / 12417610343
• BMW: 12-41-2-354-701 / 12412354701 / 12-41-2-344-243 / 12412344243
• 0-001-107-423 / 0001107423 / 0-001-107-424 / 0001107424
• 0-001-107-527 / 0001107527 / 0-001-107-528 / 0001107528 / 0-986-021-500 / 0986021500
• 428000-1760 / 4280001760
• Lucas: LRS02298
• Marelli: 63521074230
SPECIFICATIONS:
• Type: PMGR (Permanent Magnet Gear Reduction)
• Voltage: 12V
• Power: 1.2kW / 1.61HP
• Rotation: CW (Clockwise)
• Teeth: 9
• Pinion OD: 28.7mm / 1.13in
• Mounting: (1) M10x1.50 Threaded + (1) 11.2mm Unthreaded
• Condition: New
BMW APPLICATIONS:
• 1-Series: 1M, 128i, 135i 3.0L L6 (2008-2011)
• 3-Series: 323i 2.5L, 325i/xi, 328i/xi/xDrive, 330Ci/i/xi, 335i/is/xi 3.0L L6 (2006-2011)
• 5-Series: 525i/xi, 528i/xi/xDrive, 530i/xi, 535i/xi/GT 3.0L L6 (2006-2011)
• 7-Series: 740i, 740Li 3.0L L6 (2011)
• X-Series: X3, X5, X6 3.0L L6 (2007-2011)
• Z4 3.0L L6 (2006-2011)
• Engines: N52B30, N52B25, N51B30 (NA) / N54B30 (Twin-Turbo) / N55B30 (Turbo)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
