STERLING APPLICATIONS:
• Sterling A-Line A9500 / AT9500 with the Caterpillar C-11 2004-2007
• Sterling A-Line A9500 / AT9500 with the Caterpillar C-13 2004-2007
• Sterling A-Line A9500 / AT9500 with the Caterpillar C-15 2001-2007
• Sterling A-Line A9500 / AT9500 with the Caterpillar C-16 2001-2003
• Sterling A-Line A9500 / AT9500 with the Cummins ISM 2001-2003
• Sterling A-Line A9500 / AT9500 with the Cummins ISX 2001-2003
• Sterling Acterra 5500, 6500, 7500, 8500 with the Cummins 5.9L ISB 2004-2007
• Sterling Acterra 5500, 6500, 7500, 8500 with the Cummins 8.3L ISC 2004-2007
• Sterling Acterra 5500, 6500, 7500, 8500 with the Mercedes MBE900 2001-2007
• Sterling Condor with the Cummins 8.9L ISL 2001-2005
• Sterling Condor with the Cummins ISM 2001-2005
• Sterling Condor with the Cummins ISX 2001-2005
• Sterling L-Line 7500, 8000, 8500, 9500 with the Caterpillar C-11 2005-2007
• Sterling L-Line 7500, 8000, 8500, 9500 with the Caterpillar C-13 2005-2007
• Sterling L-Line 7500, 8000, 8500, 9500 with the Caterpillar C-15 2001-2007
• Sterling L-Line 7500, 8000, 8500, 9500 with the Caterpillar C-16 2003
• Sterling L-Line 7500, 8000, 8500, 9500 with the Caterpillar C-7 2005-2007
• Sterling L-Line 7500, 8000, 8500, 9500 with the Caterpillar C-9 2001-2007
• Sterling L-Line 7500, 8000, 8500, 9500 with the Cummins 8.3L ISC 2004-2007
• Sterling L-Line 7500, 8000, 8500, 9500 with the Mercedes MBE900 2006-2007
VOLVO APPLICATIONS:
• Volvo VHD Series with the Cummins ISM 2001-2003
• Volvo VHD Series with the Volvo VED 12 2001-2007
• Volvo VNL Series with the Cummins ISX 2000-2007
• Volvo VNM Series with the Cummins ISM 1997-2003
• Volvo VNM Series with the Volvo VED 12 2001-2007
• Volvo VT Series with the Cummins ISX 2004-2007
• Volvo WA / WC / WG / WH / WI / WX Series with the Cummins ISM 1997-2001
WESTERN STAR APPLICATIONS:
• Western Star 4900 with the Caterpillar C-13 2004-2007
• Western Star 4900EX with the Caterpillar C-15 2001-2007
• Western Star trucks with the Cummins ISM 2001-2003
• Western Star 4900, 4900EX, 6900 with the Cummins ISX 2001-2003
SPECIFICATIONS:
• Voltage: 12 volt
• Output: 145 amp
• Type: 22SI type, internal regulator, external fan
• Mount: quad pad, ears 10.7 mm and 12.5 mm unthreaded
• Regulator clock: 3:00
• B+ terminal: 5/16-18 stud, negative ground
• Pulley: ships without pulley
• Weight: 16.78 lb / 7.63 kg
• Pad mount 22SI only: J-180 hinge mount 22SI and internal fan 24SI units are different parts
