12V Starter Motor Compatible With 2001-2009 B21 Tl Tlb Compact Tractor Backhoe Loader D1005 1.0L

18418*1
DENSO PART NUMBERS:
• 228000-5590, 2280005590
• 9722809-559, 9722809559

KUBOTA PART NUMBERS:
• 6A100-31150, 6A10031150
• 6A100-31151, 6A10031151
• 6A100-31154, 6A10031154

OTHER PART NUMBERS:
• Wilson 91-29-5556, 91295556
• Remy RS41282

SPECIFICATIONS:
• Type: starter motor, PMGR (permanent magnet gear reduction)
• Voltage: 12 volt
• Power: 0.8 kW
• Rotation: clockwise (CW)
• Pinion: 9 tooth steel gear, gear OD 28.9 mm (1.138 in)
• Mounting flange: 77 mm
• Mounting ears: 2, both 9.0 mm ID unthreaded, 105 mm apart
• Drive distance: 18 mm
• Total length: 203 mm (distance back 148.5 mm, distance front 52.5 mm)
• B+ terminal: M8
• Plug: 30H
• Weight: 6.8 lb (3.1 kg)
• Condition: New aftermarket

PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Was: $221.36
Sale: $126.49
Save: 43%
Save: $94.87
Qty:
Free Shipping!

Description

KUBOTA COMPACT TRACTORS:
• Kubota B21 TL (Tractor Loader) with the Kubota D1005 21HP 3-cylinder 1.0L diesel 2001-2009
• Kubota B21 TLB (Tractor Loader Backhoe) with the Kubota D1005 21HP 3-cylinder 1.0L diesel 2001-2009
• Kubota B21 4WD compact tractor with the Kubota D1005 21HP diesel

KUBOTA INDUSTRIAL ENGINES:
• Kubota D11 Industrial Engine 1996-2006

ENGINE:
• Kubota D1005 3-cylinder 1.0L diesel, 21HP (B21 TL and B21 TLB)

SPECIFICATIONS:
• Type: starter motor, PMGR (permanent magnet gear reduction)
• Voltage: 12 volt
• Power: 0.8 kW
• Rotation: clockwise (CW)
• Pinion: 9 tooth steel gear, gear OD 28.9 mm (1.138 in)
• Mounting flange: 77 mm
• Mounting ears: 2, both 9.0 mm ID unthreaded, 105 mm apart
• Drive distance: 18 mm
• Total length: 203 mm (distance back 148.5 mm, distance front 52.5 mm)
• B+ terminal: M8
• Plug: 30H
• Weight: 6.8 lb (3.1 kg)
• Condition: New aftermarket

Details

Shipping Information

  • Item Requires Shipping
  • 10.0 lbs.
  • W6.0000” x H6.0000” x L10.0000”
  • Free Shipping!
