JOHN DEERE PART NUMBERS: • RE501060
• RE501150
• RE501050
• RE69705
• RE70958
• TY24443
• SE501406
• RE501888
• RE500748
DENSO PART NUMBERS: • 228000-7410, 2280007410
• 228000-7411, 2280007411
• 228000-7412, 2280007412
• 228000-7413, 2280007413
• 228080-7413, 2280807413
• TG228080-7413, TG2280807413
• 228000-6560, 2280006560
• 228000-6561, 2280006561
• 228000-6562, 2280006562
• 228080-6562, 2280806562
• TG228080-6562, TG2280806562
• 280-7064, 2807064
• DSN2027
• DSN2147
WILSON PART NUMBERS: • 91-29-5608, 91295608
• 91-29-5607, 91295607
• 91-29-5469, 91295469
• 91-29-5469N, 91295469N
LUCAS PART NUMBERS: • LRS03893, LRS3893
• LES0748
OTHER PART NUMBERS: • Liebherr 10424195
• Kohler GM81904
• MES S5736M
SPECIFICATIONS: • Voltage: 24 volt
• Type: offset gear reduction (OSGR)
• Power: 7.5 kW (John Deere and Denso also list it as 7.8 kW)
• Rotation: clockwise (CW)
• Pinion: 11 tooth, 39.8 mm (1.567 in) gear OD
• Flange: 89 mm, three unthreaded mounting ears, 11.4 mm
• Terminals: M12 battery stud and M12 ground stud
• Clutch: wet, oil sealed
• Length: 244 mm
• Weight: 23.8 lb (10.8 kg)
• Fit check: 12 volt 4.8 kW and 24 volt 5.5 kW or 6.0 kW Denso starters look alike, match voltage, kW and the number on your old starter
• Condition: New aftermarket
