KOMATSU PART NUMBERS: • 600-813-6421, 6008136421
• 600-813-6422, 6008136422
• 600-813-6420, 6008136420
• 600-813-6410, 6008136410
• 600-813-6411, 6008136411
• 600-813-6412, 6008136412
• 600-813-6413, 6008136413
• 600-813-6510, 6008136510
• 600-813-6520, 6008136520
NIKKO PART NUMBERS: • 0-23000-3301, 0230003301
• 0-23000-3302, 0230003302
• 0-23000-3300, 0230003300
• 0-23000-3290, 0230003290
• 0-23000-3291, 0230003291
• 0-23000-3292, 0230003292
• 0-23000-3295, 0230003295
• 02-23-2037, 02232037
SAWAFUJI PART NUMBERS: • 0351-602-0421, 03516020421
• 0351-602-0413, 03516020413
• 0351-602-0411, 03516020411
WILSON PART NUMBERS: • 91-28-4051, 91284051
LUCAS PART NUMBERS: • LRS02761, LRS2761
SPECIFICATIONS: • Family: Nikko / Sawafuji (Komatsu OE)
• Type: OSGR (offset gear reduction)
• Voltage: 24 Volt
• Power: 7.5 kW
• Rotation: Clockwise (CW)
• Pinion: 12 teeth, 46.4 mm (1.827 in) OD
• Flange: 92 mm
• Mounting: three 17 mm unthreaded ears
• Length: about 308 mm
• Terminal: M10 battery stud, control relay fitted
• Weight: about 30 to 35 lb (14.9 to 16 kg)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
