OEM PART NUMBERS:
• Yanmar: 128170-77010 / 12817077010
• Yanmar: 128170-77010D / 12817077010D
• Hitachi: S114-303 / S114303
• Hitachi: S114-303A / S114303A
• Bosch: SR5052N
• Quicksilver/Mercury Marine: 8M6007438
SPECIFICATIONS:
• Type: DD (Direct Drive) / Hitachi System
• Voltage: 12V / Power: 1.2kW
• Rotation: Clockwise (CW) / Teeth: 9
• Pinion/Gear OD: 29.1mm (1.146")
• Mounting Ears: 10.7mm ID Unthreaded (x2)
• Weight: 7.9 lbs (3.59 kg)
• Condition: New
YANMAR MARINE DIESEL APPLICATIONS:
• 1GM / 1GM10 / 1GM10C / GMF — 1-Cyl (1980-On)
• 2GM / 2GM20 / 2GMF / 20GM — 2-Cyl (1980-2005)
• 3GM / 3GM30 / 3GMD / 3GMF / 30GM — 3-Cyl (1980-2005)
• KM2A/C/P and KM3A/P/V Marine Gear Applications
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
