OEM PART NUMBERS:
• Prestolite: MBD5112, MBD5112S
• Ohio Motors: D468210XWF02, D468237XWF07A, D468242XWF07, D468247XW07A, D468247XWF07A, D468250XWF07, D468250XWF07A, D468255XWF07A, D482252X7707A
• JS Barnes / Haldex: 2200353, 2200858, 2200980
• JLG: 3160263, 3160264, 7011041
• Western Motor: W-5112, W5112
SPECIFICATIONS:
• Voltage: 24V DC
• Power: 4 HP
• Rotation: CW (Clockwise)
• Field Housing OD: 127mm / 5.000in
• Overall Length: 285mm / 11.220in
• Shaft: Chrysler Amplex Coupler Type
• Terminal 1: 3/8-16
• Terminal 2: 3/8-16
• Bearings: Double Ball Bearing
• Housing: Cast Aluminum Comm. and Drive Ends with Black Field Case
• Weight: 34.5 lbs / 15.68 kg
• Condition: New
APPLICATION:
• JLG 1532E2/1932E2/2032E2/2632E2/2646E2/3246E2 Scissor Lifts (1998-2012)
• Haldex Barnes / Ohio Motors Hydraulic Pump Assemblies
24V Scissor Lift Pump Motor - JLG E2 Series Replacement
Factory-fit 24 Volt electric hydraulic pump motor engineered for JLG E2 series electric scissor lifts. Direct replacement for all six E2 models: 1532E2, 1932E2, 2032E2, 2632E2, 2646E2, and 3246E2 manufactured from 1998 through 2012. This 4 HP clockwise motor with Chrysler Amplex coupler shaft provides the hydraulic pressure needed for scissor lift elevation and drive functions. Double ball bearing construction and cast aluminum housing ensure long service life in rental fleet and construction site applications. Replaces Prestolite MBD5112, Ohio D468255XWF07A, and Haldex 2200353.
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
