OEM PART NUMBERS:
• Kawasaki: 13001-3725 / 130013725
• Kawasaki: 13001-2094 / 130012094
SPECIFICATIONS:
• Type: Piston Kit (Standard Bore)
• Bore Size: 75.00mm Standard (2.953")
• No Boring Required — Light Hone to Break Glaze
• Kit Includes: (1) Piston + (1) Ring Set (Japanese RIK Performance)
• Cylinder Service: 1 (Single-Cylinder Engine)
• JS550 Clearance: 0.0045"-0.005" (Piston Port)
• 550SX Clearance: 0.006"-0.008" (Reed Valve)
• Engine: 531cc Single-Cylinder 2-Stroke
• Standard Bore: 75mm
• Weight: 2 lbs
• Condition: New
PISTON SIZE CHART (Kawasaki 550):
• Standard: 75.00mm (010-812K) — THIS KIT
• 0.25mm Over: 75.25mm (010-812-04K)
• 0.50mm Over: 75.50mm (010-812-05K)
• 0.75mm Over: 75.75mm (010-812-06K)
• 1.00mm Over: 76.00mm (010-812-07K)
APPLICATIONS:
• Kawasaki JS550 531cc Single-Cyl 2-Stroke (1982-1988)
• Kawasaki 550SX 531cc Single-Cyl 2-Stroke (1989-1990)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
