OEM PART NUMBERS:
• Isuzu: 1811001410 / 1-81100-141-0
• Isuzu: 1811001411 / 1-81100-141-1
• Isuzu: 5811001180 / 5-81100-118-0
• Isuzu: 8811002531
• Denso: 028000-6200 / 0280006200
• Denso: 028000-6201 / 0280006201
• Denso: 028000-6202 / 0280006202
• Hitachi: S25-103 / S25103
• Hitachi: S25-103A / S25103A
• Lucas: LRS01872 / LRS1872
SPECIFICATIONS:
• Type: OSGR (Offset Gear Reduction)
• Voltage: 24V
• Power: 4.5 kW
• Rotation: Clockwise (CW)
• Tooth Count: 11
• Gear OD: 40.1mm / 1.579"
• Mounting: 3x 13.0mm Unthreaded Ears
• Clutch: Dry Clutch
• Weight: 19.555 lbs / 8.89 kg
• Length: 358mm
• Flange Diameter: 105mm
• Condition: New
ISUZU INDUSTRIAL ENGINE APPLICATIONS:
• Isuzu 6BB1 5.4L Inline 6-Cyl OHV Diesel Industrial Equipment (1976+)
• Isuzu 6BD1 5.8L Inline 6-Cyl OHV Diesel ~142HP
• Isuzu 6BF1 Inline 6-Cyl OHV Diesel Industrial Equipment
• Isuzu 6BG1 6.5L Inline 6-Cyl OHV Diesel ~129HP
• Hitachi EX200-5, EX200-6, ZX200, ZX210, ZX240 Excavators w/ 6BG1
• Link-Belt LS2800 (6BD1), LS3400 (6BG1) Excavators (1988)
• Sumitomo SH200A3 Excavator w/ 6BG1
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
