OEM PART NUMBERS:
• OMC/BRP: 432925 / 438878 / 586257 / 586286 / 586287
• Johnson Electric: 5294840 / 6858540 / SM65858
• United Technologies: 5249840-M030SM / 5249840M030SM / SM52498
• United Technologies: 6858540-M030SM / 6858540M030SM / SM685854
• Prestolite: 20513535TBA
• Sierra Marine: 18-5612
• ARCO Marine: 5363 / 5391
• Quicksilver: 50-8M6007314
SPECIFICATIONS:
• Unit Type: OMC Marine PMDD (Permanent Magnet Direct Drive)
• Voltage: 12V
• Rotation: Clockwise (CW)
• Drive: 7mm x 9.5mm Drive Tang on Armature Shaft
• Mounting Ear 1: 5/16-18 ID Threaded
• Mounting Ear 2: 5/16-18 ID Threaded
• Mounting Ear 3: 9.0mm ID Unthreaded
• Field Housing Length: 4.09in / 104mm
• CE Housing: (2) 1/4-20 Mounting Holes
• Weight: 5.6 lbs / 2.55 kg
• Condition: New
EVINRUDE OUTBOARD APPLICATIONS:
• Eagle Series V6 2.6L 158ci 150-175HP (1991-1998)
• FICHT V6 2.6L 158ci 150-175HP (1997-2006)
• FICHT 75-135HP (1998-2006)
JOHNSON OUTBOARD APPLICATIONS:
• Eagle Series V6 2.6L 158ci 150-175HP (1991-2006)
• FICHT / DI V6 158ci 90-175HP (1997-2006)
• V4 FICHT 75-115HP (1998-2006)
