OEM PART NUMBERS:
• OMC/BRP: 584818 / 0584818
• OMC/BRP: 586277 / 0586277
• OMC/BRP: 586272
• United Technologies: 5711640 / 5711640-M030SM / 5711640MO30SM
• United Technologies: SM57116
SPECIFICATIONS:
• Type: PMDD (Permanent Magnet Direct Drive)
• Voltage: 12V
• Rotation: CCW (Counterclockwise)
• Tooth Count: 10
• Gear OD: 1.248" / 31.7mm
• Field Housing Length: 3.46" / 88mm
• Mounting: 2x 8mm Unthreaded Ears
• Starter Drive: 2-Piece Rubber
• Weight: 9 lbs
• Condition: New
EVINRUDE & JOHNSON OUTBOARD APPLICATIONS:
• Evinrude 25HP 3-Cyl 30.5ci 2-Stroke: E25KL, E25QL, E25TKL, E25PL, E25RE, E25RL, E25RME, E25RML, E25TKE (1996-1999)
• Evinrude 35HP 3-Cyl 34.5ci 2-Stroke: E35KL, E35QL, E35TKL, E35RML (1996-2001)
• Evinrude BE-Series 25HP 3-Cyl: BE25ARE, BE25ARL, BE25KE, BE25KL, BE25QL (1996-1998)
• Evinrude BE-Series 35HP 3-Cyl: BE35ARE, BE35ARL, BE35ARS, BE35KE, BE35KL, BE35KS, BE35QL, HE35RML (1996-2001)
• Johnson 25HP 3-Cyl 30.5ci/31.8ci 2-Stroke: 25KL, 25PL3, 25QL, 25R3, 25RL3, 25RM, 25RV3, 25RVL3, 25TK, 25TEL3, 25TVL3, 25VL3 (1996-2001)
• Johnson 35HP 3-Cyl 34.5ci 2-Stroke: 35KL, 35PL3, 35QL, 35R3, 35RL3, 35RV3, 35RVL3, 35TKL, 35TEL3, 35TVL3, 35VL3, 35E3, 35EL3 (1996-2001)
AFTERMARKET CROSS REFERENCE:
• Arco Marine: 5398
• Sierra: 18-5631
• Quicksilver: 8M6007324
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
