OEM PART NUMBERS:
• Tecumseh: 36914
• Tecumseh: 37425
• Tecumseh: 730326
• Tecumseh: 36853
SPECIFICATIONS:
• Type: PMDD (Permanent Magnet Direct Drive)
• Voltage: 12V
• Rotation: Counterclockwise (CCW)
• Tooth Count: 10
• Gear OD: 1.201" / 30.5mm
• Field Case Length: 3.66" / 93mm
• Overall Body Length: 4.72" / 120mm
• Center-to-Center Mount: 3 3/8"
• Mounting Ear 1: 8.6mm Unthreaded
• Mounting Ear 2: 8.6mm Unthreaded
• Weight: 5.205 lbs / 2.37 kg
• Note: Replaces earlier 4-bolt mount style 36914
• Condition: New
TECUMSEH ENGINE APPLICATIONS:
• OHV110/OHV115/OHV120/OHV125/OHV130/OHV135 (11-13.5 HP OHV)
• OH50/OHH50 (5.0 HP OHV Horizontal)
• OV358 (358cc OHV)
• LEV115, OVRM40, TVS90
• Case, MTD, Yardman, Yard Machine equipment
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
