OEM PART NUMBERS:
• Superwinch: 1102 / 1102D / 1110 / 1307 / 1646 / 90-33293 / SW801-005A / B01-006A
• Western Motor: W-8023 / W-8823
• Ref: 430-22015
SPECIFICATIONS:
• Voltage: 12V DC
• Rotation: Reversible (Bi-Directional)
• Power: 1kW / 1.34 HP
• Shaft OD: 13.2mm (0.520 in) - 4.32mm Flat Tang
• Shaft Height: 0.600 in from Case End
• Shaft Note: Flats on Each Side at Drive End
• Terminal: Dual 1/4-28 Posts
• Field Housing OD: 80mm / 3.150 in
• Overall Length: 182mm / 7.165 in
• Mounting: 1/4-20 Thru Bolts
• Weight: 6.2 lbs / 2.82 kg
• Condition: New
APPLICATION:
• Superwinch 1102 / 1102D / 1110 / 1307 / 1646 Series Winches
• Snowbear Snow Plow Winch Systems
• Truck Tarp Cover Motor Systems (3 Inch Motors)
PRODUCT NOTICE:
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
WARNING - This product may expose you to chemicals such as Lead, Carbon Black, Silica, Crystalline which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
